20 meter engineering car washing machine

Main products:reciprocating automatic car washing machine series, tunnel type automatic car washing machine series, bus automatic car washing machine series, contactless car washing machine series, etc.
Contacts：Mr. Liu
TEL：+8617163667888
EMAIL：zh_xcj@163.com
Our company sincerely invites you to visit our enterprise. We look forward to your arrival and are confident that we will leave a deep impression on you. Our company always adheres to the customer's needs as the guide, aiming to create high quality, high reliability, and high degree of automation. We take it as our responsibility to provide services and develop and produce various models of car washing equipment for customers based on industry core technology and years of experience. We believe that through this visit, you will have a better understanding of our company's strength and competitive advantages。 If you agree to visit, please contact us by email or phone to confirm the time。

COMMODITY INFORMATION

20 meter engineering car washing machine
Device Model	20-MGT
Device dimensions	Length 20 * Width 4.6 * Height 2.3(m)
cleaning time	10-180second/unit
Car washing method	Traveling style
Cleaning area	Tires and body
Startup method	Automatic/Manual/Human Machine Interface
Equipment power	110KW (including 45KW air drying fan)
Water supply	Circulating water tank sedimentation water/floating ball automatic replenishment
rated voltage	380v
control system	PLC integrated control

Working principle of through type engineering car washing machine

1.The direction of the equipment entering the vehicle first uses the first swing water knife high-pressure water mist spraying device to comprehensively and flawlessly soften and wash the coal slurry attached to the vehicle tires and body sides, in order to reduce adhesion.

2.The vehicle enters the second swing water high-pressure flushing, causing attachments (such as coal ash, coal slurry, etc.) to fall off with the high-pressure flushing of the sprayed water, meeting the cleaning requirements; The high-pressure nozzle at the bottom thoroughly cleans the mud and sand on the flat and side surfaces of the tire

3.After the vehicle enters the high-pressure cleaning area of the third swing water jet, the left and right high-pressure water jet devices set on both sides are activated by light sensing to thoroughly clean and drop the residual mud and sand from the vehicle tires, meeting the cleaning requirements

4.After leaving the cleaning area, enter the shaking and drying area. The tire parts pass through the bump belt device, forming the principle of up and down bumps, forcing the residual water on the vehicle body to shake down and achieve the drying effect; At the same time, the fans on both sides are started to air dry vigorously.。

5. After all homework is completed, the vehicle drives out of the work area at a constant speed, and a cleaning process ends. The system enters the waiting program.
